Pac Maxx+
Tire Description:
The Pac Maxx+ is designed to provide excellent flotation characteristics and minimal soil disturbance on packer and hauling applications.Engineered for:
Combines \ Spreaders \ Soil Compactor
| SizeTire Size | PRPly Rating | TypeTire Type | RimRim Width | O.D.Outside
Diameter |
S.W.Section Width | T.D.Tread Depth | Infl.P.Inflation Pressure | L.C.C. (lbs/kg) Load Carrying Capacity (lbs/kg) |
L.C.C. (lbs/kg) Load Carrying Capacity (lbs/kg) |
L.I.Load Index |
| in mm |
in mm |
32nds mm |
psi kPa |
5 mph 10 kph |
10 mph 15 kph |
|||||
| 23.1-26 | 12 | TL | DW20 | 61.7 1567 |
23.4 594 |
23 18 |
32 220 |
13400 6100 |
8550 3875 |
155A8 |
| 28L-26 | 16 | TL | DW25 | 62.6 1590 |
28.2 716 |
34 27 |
36 250 |
17000 7710 |
10500 4750 |
162A8 |
R-3
The Pac Maxx+ is designed to provide excellent flotation characteristics and minimal soil disturbance on
packer and hauling applications.
Engineered for: Combines \ Spreaders \ Soil Compactor
